ICON 4.5″ Lift Kit Stage 3 for 2014-2018 RAM 2500 4WD Air Ride

Description
ICON 4.5″ Lift Kit Stage 3 for 2014-2018 RAM 2500 4WD Air Ride

ICON Ram 2500 4WD Stage 3 4.5 inches Lift Suspension System (2014–2018)

Part Number: K214523A

Summary: The ICON Stage 3 suspension system provides a 4.5 inches lift height for the 2014–2018 Ram 2500 4WD, specifically engineered for models equipped with OEM Rear Air Ride. This system features ICON 2.5 Series Remote Reservoir shocks with CDC Valve technology, allowing for tool-free compression damping adjustments to suit varying terrain or towing loads. By utilizing dual-rate coil springs and specialized rear air ride spacers, this system ensures a level stance and superior off-road performance while maintaining full factory air ride functionality.

Features

• Dual-Rate Coil Springs: ICON-engineered 4.5” dual-rate front springs provide exceptional vehicle control and a plush ride over varying terrain to ensure balanced performance.
• CDC Valve Technology: The Compression Damping Control (CDC) Valve provides 10 levels of user-adjustable damping to ensure optimal ride quality for daily driving or spirited off-road use.
• 2.5 Series Aluminum Shocks: One-piece impact extruded aluminum cylinders provide excellent corrosion resistance and heat dissipation to ensure consistent damping under high-demand conditions.
• System Durability: High-strength laser-cut bracketry and billet bump stop spacers provide maximum structural integrity to ensure long-term reliability in harsh environments.
• Installation: Direct-fit design and included hardware provide a comprehensive bolt-on solution to ensure simplified installation and retention of factory air ride components.

Technical Specifications

Wheel & Tire Fitment

• OEM Wheels & Tires: Yes
• Aftermarket Wheels: 17×8.5 inches w/ 5.25” BS / 13mm Offset, 18×9 inches w/ 5.50 inches BS / 12mm Offset, or 20×9 inches w/ 5.50 inches BS / 12mm Offset
• Aftermarket Tires: 37 inches x 12.50 inches
• Note: Larger tires may fit but fender trimming and modifications will be required. Springs are rated for Diesel engines only. May not be compatible with other manufacturers’ aftermarket track bars.

System Components

• 214201 (qty: 1) | 14-UP RAM 2500 4.5 inches FRONT DUAL RATE SPRING KIT
• 214214 (qty: 1) | 14-UP RAM 2500 FRONT ADJUSTABLE TRACK BAR KIT
• 214204 (qty: 1) | 14-UP RAM 2500 REAR ADJUSTABLE TRACK BAR KIT
• 214205 (qty: 1) | 14-UP RAM 2500 4.5 inches BOX KIT
• 214210 (qty: 1) | 14-UP RAM 2500 3.75\” REAR AIR RIDE KIT
• 217803CP (qty: 1) | 14-UP RAM 2500 4.5 inches FRONT 2.5 VS RR CDCV PAIR
• 217704CP (qty: 1) | 14-UP RAM 2500 0 inches COIL / 3 inches AIR RIDE REAR 2.5 VS PB CDCV PAIR

Why Choose ICON Stage 3?

• Performance Engineering: Increased wheel travel and damping for superior control without sacrificing towing capacity.
• Compression Adjustability: The CDC Valve allows for instant tuning of your suspension to match your load or terrain.
• Fully Serviceable: Shocks are rebuildable and revalveable for long-term performance and custom tuning.

Frequently Asked Questions

Will this kit work with gas engine Ram 2500s?
No
