Bilstein/OME 5100 1.5-3″ Lift Assembled Coilovers for 1996-2002 Toyota 4Runner

SKU: B4R96C
5 out of 5 based on 3 customer ratings
(3 customer reviews)
Sale!
Bilstein 5100 1.5-3" Lift Assembled Coilovers for 2000-2006 Toyota Tundra
Bilstein 5100 1.5-3" Lift Assembled Coilovers for 2000-2006 Toyota Tundra

Description
Bilstein/OME 5100 1.5-3″ Lift Assembled Coilovers for 1996-2002 Toyota 4Runner

Bilstein/OME 5100 1.5-3″ Front Lift Pre-Assembled Coilovers – 1996-2002 Toyota 4Runner

Part: B4R96C

Get real lift and control without the hassle. These front Bilstein 5100 ride-height-adjustable struts come pre-assembled with ARB/OME coils, new top mounts, and hardware, so you skip the spring compressor and bolt them in. The 46 mm monotube 5100s add wheel travel and keep damping consistent on-road and off-road.

Need a kit with rear shocks as well?

or the full package

What’s Included

  • 2 x Bilstein 5100 front struts, snap-ring perch bodies
  • 2 x ARB/OME front coil springs (your choice below)
  • New strut mounts, isolators, dust boots, and hardware
  • Professionally pre-assembled coilover units

Coil Options

  • OME 2880 – stock front weight, ~1.5″ lift
  • OME 2881 – stock front weight, ~2-2.5″ lift
  • OME 2883 – +200 lb constant front weight (heavy bumper + winch), ~2.5-3″ lift

Preset Perch Setting

Coilovers are set on Clip 1 (lowest). The OME coils provide the lift. Do not raise the clip for extra height. Setting higher than Clip 1 will over-lift the front, can damage CVs/ball joints, and voids warranty.

Fitment

  • Vehicle: Toyota 4Runner 1996, 1997, 1998, 1999, 2000, 2001, 2002
  • Lift range: ~1.5-3″ depending on coil choice and vehicle weight

Why You’ll Like It

  • No spring compressor needed – arrives fully assembled
  • Bilstein 5100 control – 46 mm monotube, digressive valving for consistent, fade-resistant damping
  • OME-matched coils – real-world ride height, improved handling and wheel travel

Important Notes

  • Depending on the coil option, spring free lengths may differ. Install the taller spring on the driver side to compensate for driver weight and the fuel tank.
  • Alignment is required after installation. Expect minor settling in the first few drives.

FAQ

Do these add rear lift? No, this is a front-only kit. Add rear shocks/springs via

or
.

Can I change the clip later? We strongly recommend leaving it at Clip 1 with OME coils. Raising the clip can over-lift and cause damage.

Customer reviews

Rated 5 out of 5 stars
3 reviews
5 stars 3 100 %
4 stars 0 0 %
3 stars 0 0 %
2 stars 0 0 %
1 star 0 0 %

3 reviews for Bilstein/OME 5100 1.5-3″ Lift Assembled Coilovers for 1996-2002 Toyota 4Runner

Add a review

Use one of the allowed file type: jpg,png,jpeg.

    Questions and answers of the customers

      Purchased the front coilovers for my ‘99 4Runner Ltd 4WD. OME 881s. I’ve got the originals removed and noticed no indication as to which is for driver and which for passenger? Aren’t they supposed to be side specific?
    1. 0 votes
      Q Purchased the front coilovers for my ‘99 4Runner Ltd 4WD. OME 881s. I’ve got the originals remove...... Read more answer now
      A no sir, OME coils are not side specific as they are stronger than stock
      2. can i use the 2881s on the 2nd clip to get 3 inch of lift? (stock weight)
    2. 0 votes
      Q can i use the 2881s on the 2nd clip to get 3 inch of lift? (stock weight) answer now
      A No This may cause damage
      3. I’m interested in the front coilovers assembled with 881s. What model of Bilsteins are included? My understanding was that 24-248730 was the correct model for my ‘99 4Runner Ltd 4WD. Please let me know.
    3. 0 votes
      Q I’m interested in the front coilovers assembled with 881s. What model of Bilsteins are included? ...... Read more answer now
      A Yes Coilovers will fit for you truck These are 24-248730
      4. So, if I want to achieve a 2-2.5" lift on the front, so I need to move the clip up a spot from the stock (lower) setting? Or does the spring provide that particular lift? I have the 2881 springs.
    4. 0 votes
      Q So, if I want to achieve a 2-2.5" lift on the front, so I need to move the clip up a spot from th...... Read more answer now
      A The OME 2881 spring (Stock front weight. 2-2.5 inch lift.) will provide a lifting height of 2-2.5 inch lift. at the lowest position of the ring. There is no need to move the ring higher, otherwise it can lead to breakage
      5. Could you give us the overall height from lower bushing center to top mounting surface please? Thank you.
    5. 0 votes
      Q Could you give us the overall height from lower bushing center to top mounting surface please? Th...... Read more answer now
      A Collapsed Length (IN)13.66 Extended Length (IN)18.27
      6. Will these fit a 98 Tacoma 4x4
    6. 0 votes
      Q Will these fit a 98 Tacoma 4x4 answer now
      A Yes Will fit for 98 Tacoma 4x4
      7. Is this priced at 2 struts? Feel dumb for asking
    7. 0 votes
      Q Is this priced at 2 struts? Feel dumb for asking answer now
      A coilover are priced per pair as pictured
      8. Will these work on a 1999 Toyota 4runner that is a 2wd?
    8. 0 votes
      Q Will these work on a 1999 Toyota 4runner that is a 2wd?
      There are no answers for this question yet. Answer now
      9. So when you say 2.5-3 inch lift on the 2883 does that mean lowest clip and nothing hire?
    9. 0 votes
      Q So when you say 2.5-3 inch lift on the 2883 does that mean lowest clip and nothing hire? answer now
      A

      yes, you are right, not higher
