ICON 2.5 VS Stage 10 3.5-4.5″ Tubular Lift Kit for 2023 Toyota Sequoia

Description
ICON 2.5 VS Stage 10 3.5-4.5″ Tubular Lift Kit for 2023 Toyota Sequoia

ICON 2023–2025 Toyota Sequoia 3-4.5 inches Lift Stage 10 Suspension System Tubular CDCV

Part Number: K53240T

Summary: The ICON Stage 10 suspension system for the 2023–2025 Toyota Sequoia is a top-tier performance upgrade designed to provide 3-4.5 inches of front lift and 2 inches of rear lift. This system builds upon lower stages by integrating tubular rear upper and lower links alongside an adjustable rear track bar for complete axle control and pinion angle adjustment. Featuring 2.5 Series CDCV coilovers and rear shocks, this stage provides maximum adjustability and damping for superior on-road handling and high-speed off-road performance.

Features

• CDC Valve Technology: All shock absorbers equipped with CDC Valves provide 10 settings of compression damping adjustment to ensure precise ride control for varying terrain and cargo loads.
• Delta Joint Pro: Patented (U.S. Pat. 10,731,700) Delta Joint Pro provides 90 degrees of total articulation to ensure maximum wheel travel without binding or premature wear.
• Tubular Link Kit: Rear upper and lower links with adjustable track bar provide pinion angle correction and axle centering to ensure proper suspension geometry and improved articulation.
• System Durability: 2.5 Series remote reservoir shocks with aluminum bodies provide superior cooling and corrosion resistance to ensure consistent damping during aggressive use.
• Installation: Vehicle-specific design provides direct fitment to ensure a straightforward installation process utilizing factory mounting locations.

Technical Specifications

Wheel & Tire Fitment

• OEM Wheels & Tires: Yes
• Aftermarket Wheels: 17×8.5 inches w/ 5.75” Backspace (25mm Offset) or 18×9 inches w/ 6” Backspace (25mm Offset)
• Aftermarket Tires: 35 inches x 12.50 inches
• Note: Minor fender trimming and modifications may be required. Advertised lift height ranges are for a stock equipped vehicle. Not compatible with Adaptive Variable Suspension (AVS) or Load-Leveling Rear Height Control Air Suspension.

System Components

• 58770C | 22-25 TUNDRA/23-25 SEQUOIA 2.5 VS RR CDCV COILOVER KIT
• 58461DJ | 22-25 TUNDRA/23-25 SEQUOIA TUBULAR UCA DJ PRO KIT
• 55154 | 22-25 TUNDRA/23-25 SEQUOIA SWAY BAR DROP KIT
• 54002T | 22-25 TUNDRA/23-25 SEQUOIA/24-25 TACOMA TUBULAR REAR LOWER LINK KIT
• 54102T | 22-25 TUNDRA/23-25 SEQUOIA/24-25 TACO/LC250/GX550/25 T4R TUBE UPR LINK KIT
• 57840CP | 22-25 TUNDRA 0-1.5 inches/23-25 SEQUOIA 0-4 inches REAR 2.5 VS CDCV RR PAIR
• 51212 | 23-25 SEQUOIA 2 inches DUAL RATE REAR SPRING KIT
• 54202 | 22-25 TUNDRA/23-25 SEQUOIA/24-25 TACO/LC250/GX550/25 T4R BLT ADJ TRACK BAR

Why Choose ICON Stage 10?

• Performance Engineering: Increased wheel travel and damping for superior control in extreme off-road conditions.
• Delta Joint Reliability: High-angle articulation with a sealed, greaseable design for long-term durability.
• Fully Serviceable: Shocks are rebuildable and revalveable for long-term performance and custom tuning.

Frequently Asked Questions

What is the benefit of the CDCV (Compression Damping Control) Valve?
The CDCV allows you to externally adjust the damping of your shocks with 10 distinct settings, ranging from soft for daily driving to firm for high-speed off-road use.

Does this kit require any additional parts for 4WD models?
Yes, for 4WD models without the TRD Off-Road package, ICON recommends using an ICON Diff Drop (Part# 55156) or Toyota TRD axles to prevent front axle damage.
