ICON 0-3.5″ Lift Kit Stage 10 (Tubular) for 2005-2015 Toyota Tacoma

Description
ICON 0-3.5″ Lift Kit Stage 10 (Tubular) for 2005-2015 Toyota Tacoma

ICON 2005–2023 Toyota Tacoma 0-3.5 inches Lift Stage 10 Suspension System, Tubular UCA

Part Number: K53010T

Summary: The Stage 10 suspension system is a flagship performance solution for the 2005–2023 Toyota Tacoma, engineered to provide maximum wheel travel and damping ability for the serious off-road driver. This system features 2.5 Series front coilovers and specialized RXT 2.5 Series rear bypass shocks, delivering up to a 3.5 inches front lift on 2005–2015 models and 2.75 inches on 2016–2023 models. A key differentiator is the inclusion of the ICON RXT Multi-Rate Leaf Pack and the patented Delta Joint Tubular UCAs, which together provide ultimate rear articulation and front-end alignment correction.

Features

• Compression Damping Control (CDCV): Front coilovers equipped with CDC Valves provide 10 unique settings of compression damping adjustment to ensure consistent performance from soft to hard across various terrains.
• RXT Omega Bypass Shocks: 2.5 Aluminum Series rear shocks with compression and rebound adjustability provide the ultimate in ride control to ensure maximum vehicle stability under high-speed use.
• Delta Joint Technology: Patented high-angle ball joints provide the durability of a uniball with the weather resistance of a sealed joint to ensure long-term reliability and increased articulation.
• Multi-Rate Leaf Springs: RXT Multi-Rate Leaf Packs with 3 user-adjustable spring rates provide customizable load handling to ensure optimal ride quality for unique vehicle configurations.
• Increased Wheel Travel: Unique side-mounted lower eyelets on the RXT rear shocks provide up to a 20% increase in travel to ensure superior off-road capability while utilizing factory mounting locations.
• System Durability: CAD plated coilover bodies with 7/8 inches shafts and 6061 aircraft-grade aluminum components provide maximum corrosion resistance to ensure longevity in harsh environments.
• Installation: Direct-fit bolt-on design provides a straightforward upgrade path to ensure a professional fitment without major vehicle modification.

Technical Specifications

Wheel & Tire Fitment

• OEM Wheels & Tires: Yes
• Aftermarket Wheels: 17×8.5 with 4.75” Backspace / 0mm Offset; 18×9 with 5.00” Backspace / 0mm Offset; 20×9 with 5.00” Backspace / 0mm Offset
• Aftermarket Tires: 33 inches x 11.50 inches
• Note: Larger tires may fit but fender trimming and modifications will be required. Trimming required for recommended tire size. 2017–2023 Tacoma TRD Pro models will have front lift height range of 0-1.25 inches and 1.375-2.125 inches of rear lift over stock.

System Components

• 58735C (qty: 1) | 05-23 TACOMA EXT TRAVEL 2.5 VS RR CDCV COILOVER KIT
• 58450DJ (qty: 1) | 05-23 TACOMA TUBULAR UCA DJ KIT
• 158505 (qty: 2) | 05-23 TACOMA MULTI RATE RXT LEAF PACK W/ ADD IN LEAF
• 52050 (qty: 1) | TOYOTA REAR 8.0 inches U-BOLT KIT
• 59926P (qty: 1) | 05-23 TACOMA RXT REAR 2.5 OMEGA RR PAIR

Why Choose ICON Stage 10?

• Performance Engineering: Increased wheel travel and damping for superior control.
• Delta Joint Reliability: High-angle articulation with a sealed design.
• Fully Serviceable: Shocks are rebuildable and revalveable for long-term performance.

Frequently Asked Questions

Is this system compatible with 2WD 5-Lug Tacomas?
No, this system is not compatible with 2005–2015 2WD 5-Lug Toyota Tacoma models.

What is the rear lift height range for most Tacoma models?
Most Tacoma submodels will have a rear lift height range of 1.875–2.625 inches, depending on the rear spring configuration and vehicle weight.
