Bilstein/OME 5100 2″ Front Lift Assembled Coilovers and Rear 5100 Shocks for 2016-2023 Toyota Tacoma

Description
Bilstein/OME 5100 2″ Front Lift Assembled Coilovers and Rear 5100 Shocks for 2016-2023 Toyota Tacoma

Bilstein/OME 5100 2″ Front Lift Pre-Assembled Coilovers + Rear 5100 Shocks – 2016-2023 Toyota Tacoma

Part: B16CK

Get a true 2″ front lift with matched damping front and rear. These front Bilstein B8 5100 struts are pre-assembled with your choice of ARB/OME or Eibach coils and new KYB top mounts, so you skip the spring compressor and bolt them in. Rear Bilstein 5100 shocks finish the package for balanced control on pavement and trail.

What’s Included

• Front (pre-assembled coilovers): 2 x Bilstein 5100 ride-height-adjustable struts with your selected coils, new KYB top mounts, insulators, and all hardware
• Rear: 2 x Bilstein 5100 shocks (pair)

Front Coil Choices

• OME 2887 – ~2″ lift, 590 lb/in rate [stock weight]
• OME 2888 – ~2″ lift, 590 lb/in rate [aftermarket front bumper]
• OME 2886 – ~2″ lift, 660 lb/in rate [front bumper + winch]
• Eibach E30-82-069-02-20 – ~2″ lift, 742 lb/in rate

Select the spring that matches your constant front weight. Heavier-rate coils hold height with added accessories.

Important Setup Note

Coilovers are assembled on the bottom perch setting. The chosen coils provide the lift. Do not raise the snap-ring clip for extra height — over-lifting can damage suspension components and voids warranty.

Why You’ll Like It

• No spring compressor needed – faster, safer install
• Real control – Bilstein 5100 monotube design with 46 mm digressive piston for consistent, fade-resistant damping
• Matched rear shocks – improves stability, towing manners, and off-road composure

Fitment

• Vehicle – Toyota Tacoma 2016, 2017, 2018, 2019, 2020, 2021, 2022, 2023
• Drivetrain – 2WD or 4WD
• Front lift – about 2″ with the listed coils (actual height varies with trim and accessories)

Technical Notes

• Front 5100: ride-height-adjustable body, assembled at lowest clip by design
• Rear 5100: smooth-body monotube, non-reservoir, non-adjustable
• Alignment is required after installation; verify tire clearance based on wheel width/offset

FAQ

Can I move the clip higher? No. With lift coils installed, raising the clip will over-lift the front and can cause CV/ball-joint issues.

Which coil should I choose? Use 2887 for stock-weight trucks, 2888 for a steel bumper, 2886 for bumper+winch, or the Eibach option for the firmest front rate.
