ICON 0-2.75″ Lift Kit Stage 4 with Tubular UCA 2016-2023 Toyota Tacoma

Description
ICON 0-2.75″ Lift Kit Stage 4 with Tubular UCA 2016-2023 Toyota Tacoma

ICON 2005–2023 Toyota Tacoma 0-3.5 inches Lift Stage 4 Suspension System (Tubular UCA)

Part Number: K53004T

Summary: The ICON Stage 4 suspension system provides a comprehensive performance upgrade for the 2005–2023 Toyota Tacoma, offering 0-3.5 inches of front lift (model year dependent) and 1.5 inches of rear lift. This system is engineered to maximize wheel travel and damping through vehicle-specific tuned 2.5 Series remote reservoir coilovers and 2.0 Aluminum Series remote reservoir rear shocks. A key differentiator is the inclusion of ICON tubular upper control arms featuring the patented Delta Joint, which corrects suspension geometry and ensures bind-free articulation for serious off-road use.

Features

• Extended Travel Coilovers: 2.5 Series remote reservoir shocks provide increased cooling capacity and damping to ensure consistent performance during aggressive off-road use.
• Delta Joint Technology: The patented (U.S. Pat. 10,731,700) high-angle ball joint provides the durability of a standard ball joint with the performance of a racing uniball to ensure full bump and droop travel.
• Add-A-Leaf Kit: A 10% reduction in rear spring rate compared to factory overload leaves provides a more compliant ride to ensure superior comfort on and off-road.
• System Durability: CAD plated shock bodies with 7/8 inches shafts and 6061 aircraft-grade aluminum components provide maximum corrosion resistance to ensure long-term reliability in harsh environments.
• Installation: A direct-fit design provides a straightforward bolt-on process to ensure minimal vehicle downtime.

Technical Specifications

Wheel & Tire Fitment

• OEM Wheels & Tires: Yes
• Aftermarket Wheels: 17×8.5 with 4.75” BS / 0mm Offset, 18×9 with 5.00” BS / 0mm Offset, or 20×9 with 5.00” BS / 0mm Offset
• Aftermarket Tires: 33 inches x 11.50 inches
• Note: Larger tires may fit but fender trimming and modifications will be required. Not compatible with 2005-2015 2WD 5-Lug models. 2017-2023 TRD Pro models lift range is 0-1.25 inches front and 1 inches rear.

System Components

• 58735 (qty: 1) | 05-23 TACOMA EXT TRAVEL 2.5 VS RR COILOVER KIT
• 58450DJ (qty: 1) | 05-23 TACOMA TUBULAR UCA DJ KIT
• 51100 (qty: 1) | 96-23 TACOMA/00-06 TUNDRA 1.5 inches ADD-A-LEAF KIT
• 56503R (qty: 2) | 05-23 TACOMA 4WD 0-1.5\” REAR 2.0 VS RR

Why Choose ICON Stage 4?

• Performance Engineering: Increased wheel travel and damping for superior control.
• Delta Joint Reliability: High-angle articulation with a sealed design for protection against the elements.
• Fully Serviceable: Shocks are rebuildable and revalveable for long-term performance.

Frequently Asked Questions

What is the benefit of the Remote Reservoir on the Stage 4 shocks?
The remote reservoirs increase oil capacity and surface area
