ICON 0-2.75″ Lift Kit Stage 7 with Tubular UCA for 2016-2023 Toyota Tacoma

Description
ICON 0-2.75″ Lift Kit Stage 7 with Tubular UCA for 2016-2023 Toyota Tacoma

ICON ICON 2005–2023 Toyota Tacoma Stage 7 Suspension System (0-3.5 inches Lift)

Part Number: K53007T

Summary: The ICON Stage 7 suspension system is a flagship performance upgrade for the 2005–2023 Toyota Tacoma, offering 0-3.5 inches of front lift (model year dependent) and 1.5 inches of rear lift. This system is engineered to maximize wheel travel and damping ability through vehicle-specific tuned 2.5 Series Extended Travel coilovers and Omega Series Bypass rear shocks. A key differentiator is the inclusion of the patented Delta Joint Tubular Upper Control Arms and the Compression Damping Control Valve (CDCV) technology for precise track-side or trail-side adjustments.

Features

• CDCV Technology: Externally adjustable CDC Valves provide 10 levels of compression damping force ranges to ensure ultimate control across varying terrains.
• Omega Series Bypass: 2.5 Series rear shocks with 28 settings of compression and rebound adjustment provide the ultimate in ride control and specific damping zones.
• Delta Joint: Patented high-angle ball joint provides the durability of a sealed joint with the performance of a uniball to ensure long-term reliability and increased articulation.
• Extended Travel Coilovers: Vehicle-specific tuned front shocks provide maximum wheel travel to ensure superior off-road performance.
• System Durability: Corrosion-resistant CAD plated coilover shock bodies with 7/8 inches shafts and 6061 CNC machined components provide maximum longevity to ensure performance in harsh environments.
• Installation: Direct fitment design provides a straightforward bolt-on process to ensure reduced vehicle downtime.

Technical Specifications

Wheel & Tire Fitment

• OEM Wheels & Tires: Yes
• Aftermarket Wheels: 17×8.5 with 4.75” Backspace / 0mm Offset, 18×9 with 5.00” Backspace / 0mm Offset, or 20×9 with 5.00” Backspace / 0mm Offset
• Aftermarket Tires: 33 inches x 11.50 inches
• Note: Larger tires may fit but fender trimming and modifications will be required. Not compatible with 2005-2015 2WD 5-Lug models. 2017-2023 TRD Pro lift height is 0-1.25 inches front over stock.

System Components

• 58735C | 05-23 TACOMA EXT TRAVEL 2.5 VS RR CDCV COILOVER KIT
• 58450DJ | 05-23 TACOMA TUBULAR UCA DJ KIT
• 51100 | 96-23 TACOMA/00-06 TUNDRA 1.5 inches ADD-A-LEAF KIT
• 59905P | 05-23 TACOMA 0-1.5 inches REAR 2.5 OMEGA RR PAIR

Why Choose ICON Stage 7?

• Performance Engineering: Increased wheel travel and damping for superior control via 2.5 inches diameter shock bodies.
• Delta Joint Reliability: High-angle articulation with a patented sealed design for quiet, long-lasting operation.
• Fully Serviceable: Shocks are rebuildable and revalveable for long-term performance and custom tuning.

Frequently Asked Questions

What is the benefit of the CDCV system?
The CDC Valve allows for 10 specific settings of compression damping, allowing the driver to soften the ride for street use or stiffen it for high-speed off-road driving.

Does this kit require aftermarket wheels?
While it is compatible with OEM wheels and tires, ICON recommends specific aftermarket wheel dimensions (0mm offset) to ensure proper clearance for larger 33 inches tires.
