ICON S2 Secondary Shock System – Stage 1 for 2016-2023 Toyota Tacoma

Description
ICON S2 Secondary Shock System – Stage 1 for 2016-2023 Toyota Tacoma

ICON Stage 1 S2 Secondary Shock Upgrade System 0-2.75 inches Lift for 2016–2023 Toyota Tacoma

Part Number: K53125

Summary: The ICON Stage 1 S2 Secondary Shock System is a modular suspension upgrade designed for the 2016–2023 Toyota Tacoma to effectively double the front damping ability. This system allows for the installation of a secondary 2.5 Aluminum Series Remote Reservoir shock alongside an existing ICON coilover setup, providing a massive increase in off-road performance without the complexity of a long-travel kit. By utilizing the factory lower control arms and maintaining the OE track width, this system offers a robust solution for tackling larger obstacles and high-speed rough terrain with confidence.

Features

• Secondary Damping: Vehicle-specific tuned 2.5 Aluminum Series shocks provide effectively doubled damping capacity and increased oil volume to ensure superior fade resistance during aggressive off-road use.
• S2 Modular Design: A bolt-on secondary shock hoop and skid plate kit provides an affordable, step-by-step upgrade path to ensure high-end performance without the cost of long-travel conversions.
• System Durability: One-piece impact extruded aluminum cylinders provide excellent corrosion resistance and a consistent finish to ensure long-term component integrity in harsh environments.
• Installation: A mostly bolt-on design utilizing factory lower control arms (requires minor welding) provides a straightforward installation to ensure the vehicle maintains OE track width and geometry.

Technical Specifications

Wheel & Tire Fitment

• OEM Wheels & Tires: Yes
• Aftermarket Wheels: 17×8.5 inches w/ 4.75” BS (0mm Offset), 18×9 inches w/ 5.00” BS (0mm Offset), or 20×9 inches w/ 5.00” BS (0mm Offset)
• Aftermarket Tires: 33 inches x 11.50 inches
• Note: Maximum steering angle is reduced for secondary shock compatibility. Larger tires may fit but fender trimming and modifications will be required. Welding is required on the lower control arm. Does not work with TRD Big Brake Kit.

System Components

• 56107 (qty: 1) | 16-23 TACOMA SKID PLATE KIT
• 56102 (qty: 1) | 07-14 FJ/03-24 4RUNNER/05-23 TACOMA S2 SHOCK HOOP KIT
• 59706P (qty: 1) | TOYOTA S2 SECONDARY 2.5 VS RR PAIR

Why Choose ICON Stage 1 S2?

• Performance Engineering: Effectively doubles the damping capacity of the front suspension for superior control in rough terrain.
• OE Track Width: Unlike long-travel kits, the S2 system works with factory lower control arms to keep the vehicle’s footprint manageable.
• Fully Serviceable: Shocks are rebuildable and revalveable for long-term performance and custom tuning.

Frequently Asked Questions

Does this kit require welding?
Yes, welding is required on the factory lower control arm to accommodate the secondary shock mounting.

Is this compatible with aftermarket lower control arms?
No, this system requires OE front lower control arms and is not compatible with other aftermarket front lower control arm kits.
