ICON 7″ Lift 2.0 Aluminum Series Remote Reservoir Front Shock For 2005, 2006, 2007, 2008, 2009, 2010, 2011, 2012, 2013, 2014, 2015, 2016 Ford F250/F350
Part: 66514R
OVERVIEW:
ICON Vehicle Specific (V.S.) 2.0 Aluminum Series shock absorbers are the ultimate in cost effective upgrades, specifically tailored by ICON engineers for your application. The V.S. 2.0 Aluminum Series shocks are a high quality upgrade for the everyday street driver and weekend warrior looking for improved on and off-road performance. Like all ICON shock absorbers, V.S. 2.0 Aluminum Series shocks are 100% rebuildable and 100% revalveable. For those using their vehicle in extreme off road situations, consider the ICON V.S. 2.5 Series shock to handle extra abuse and punishment your suspension will need to endure.
KEY FEATURES:
Premium grade 5WT shock oil for consistent suspension damping along a wide temperature range
Nitrogen charged monotube design with remote reservoir
One piece linear/digressive piston design with vehicle specific valving for unsurpassed performance and ride quality on and off-road
5/8” chrome plated hardened steel shaft resists corrosion and pits
6061 aluminum rod end, top cap, and internals ensure strength and durability
Polyurethane bushings, zinc plated sleeves, and forged steel mounting stems for OE factory type fitment
Application-specific reservoir mounting hardware
6063 anodized aluminum body and reservoir tubing for superb heat dissipation, excellent corrosion resistance, and high-tech appearance
Nitrile rubber top out bumper for noise free operation
ICON Delta Joint Tubular Upper Control Arm Kit 2001, 2002, 2003, 2004, 2005, 2006, 2007, 2008, 2009, 2010 Chevy/GMC 2500HD/3500
Part: 78550DJ
OVERVIEW:
Take the performance of your 2001-2010 GM HD truck to new levels with the ICON Vehicle Dynamics Delta Joint tubular upper control arm kit. All ICON tubular upper control arms are constructed from CNC bent 1026 DOM steel tubing and then powder coated to a semi-gloss black finish for maximum strength and corrosion resistance. ICON upper control arms are engineered with built-in caster correction for optimal alignment specifications and confidence inspiring handling. A main benefit of ICON upper control arms is the increased wheel travel (nearly 50%) when paired with our 2.0 or 2.5 series shock absorbers, this translates into superior performance and ride quality for your 2001-2010 GM HD.
These upper control arms feature ICON’s patent pending Delta Joint. The Delta Joint is a heavy duty high angle ball joint that combines the durability of a ball joint with the performance characteristics of a traditional uniball. While the industry standard uniball does a great job of allowing the control arms of a vehicle to articulate with little bind, they do have an inherent weakness that leaves more to be desired when used in a daily driven application – exposure to the elements. The Delta Joint features a zinc plated housing providing the first layer of corrosion resistance, while a tough grease seal keeps potentially harmful elements out of the inner workings of the joint. Metal on metal construction and a greasable design increase the longevity of the Delta Joint while at the same time allowing for noise-free operation. What makes the Delta Joint unique is that it brings the best of both worlds to ICON upper control arms with features that make it more robust than a uniball, and at the same time capable of greater angularity than a typical ball joint.
KEY FEATURES:
• ICON Delta Joint
• 1026 DOM Steel Construction
• CNC Bent Tubing
• Serviceable Dual Stage Bushings
• CNC Machined Bushing Housings and Sleeves
• Built-In Caster Correction
• Black Semi-Gloss Powder Coat Finish
TECH INFO:
Fits 2WD & 4WD Applications
WHEEL & TIRE FITMENT INFO:
Factory Wheels & Tires: Yes
Aftermarket Wheels & Tires: 17″ or larger wheels with max 5.00″ back space. 20″ or larger wheels with max 5.25″ back space.
KIT COMPONENTS:
• Tubular Delta Joint Control Arms
• Dual Stage Bushing Kit
• Necessary Hardware
• Installation Instructions
OPTIONS:
• 191011 – ICON Tubular Upper Control Arm Dust Cover
ICON Vehicle Dynamics is excited to provide a sneak-peek into the development of a 2.5” suspension system for the new 2018 Jeep Wrangler JL. Aimed at drastically improving (not just maintaining) on and off-road ride quality this system includes dual rate coil springs, 2.0 Aluminum Series shocks, link arms, front and rear bump stops, sway bar end links, and all necessary hardware for a complete install. The JL is a much more “refined” vehicle compared to previous Wranglers, and with improved suspension geometry and more robust components this new Jeep sees significant performance gains with the introduction of ICON suspension products.
Through an accelerated testing process dubbed the “ICON1K” R&D program, ICON has logged over a thousand miles in the dirt pushing the JL to off-road extremes to identify limiting factors in OE components, develop products that remove these limits, and further extrapolate performance out of this vehicle. This 2.5” suspension system has been tweaked, tuned, and revised several times over the course of this ICON1K testing in an effort to provide unparalleled ride quality and vehicle dynamics for everything from rock crawling to high-speed desert running. By removing the aforementioned “limiting factors” this ICON suspension system completely redefines the potential of the 2018-UP Jeep JL with wheel travel gains over 30%!
This ICON Vehicle Dynamics 2.5” suspension system will allow for the use of a 35” tire, while ICON Alloys offers wheels in both a 4.5” and 4.75” backspace that provides ideal fitment for the varying axle widths found on Rubicon and non-Rubicon models. For those who are looking to install a 37” tire, ICON will be offering a bump stop spacer kit that allows for this as well. Additional ICON JL components are currently in development, so be sure to keep your eyes out for an official release on the COMPLETE 2.5″ suspension system lineup in the coming weeks!
Holistic Engineering – the ICON Difference
When developing suspension components for a new vehicle, ICON takes a different approach than many others. Rather than focusing in on one particular part, ICON engineers look at the vehicle as a whole, identify inherent strengths and weaknesses, and set a target for performance. With a focus on maximizing wheel travel and improving ride quality, ICON will develop components that address (and often times replace) OE limiting factors. This “holistic engineering” philosophy often results in the development of several parts designed to work together as a system to provide a balanced on and off-road performance upgrade. Because ICON is designing and manufacturing all of the components necessary to improve the performance of a vehicle from front to back, end-users can rest easy knowing they are dealing with ONE manufacturer, ONE standard of quality, and ONE awesome warranty to back it all up.
ICON Vehicle Dynamics products are proudly designed, manufactured, and assembled in Riverside, California by a team of passionate off-road enthusiasts. With a reputation for quality, performance, and service it’s clear that ICON Vehicle Dynamics is the top choice for performance suspension systems and shock absorbers for the new Jeep Wrangler JL.
KEY FEATURES
2.5″ lift height
Fits 35″ tires (37″ with bump stop spacer kit)
3″ front, 2″ rear increase in wheel travel
Improves on and off-road ride quality over stock
Dual rate coil springs with lifetime guarantee against sagging/breakage
2.0 Aluminum Series shocks with vehicle specific valving
100% bolt-on system makes for an easy install
“ICON 1K” tested under rigorous off-road conditions to validate tune, performance, strength, and durability
