Zone Offroad 4″ Strut Spacer Lift Kit 2015, 2016, 2017, 2018, 2019, 2020Ford F-150 4WD

Part: F47

Zone Offroad 2015-16 Ford F150 4wd 4″ Suspension System. This system includes the same features and benefits of the current 6″ system for those looking for the same quality and performance at a lower height.

The system is built around 2 heavy duty 1-piece lower control arm crossmembers and massive ductile cast iron steering knuckles. Differential relocation brackets place the front differential for perfect CV angles and still allow for the factory front driveshaft to perform as is should. The 4″ of lift is provided by bolt-on strut spacers do not require disassembly of the factory struts to install. New eccentric cam bolts make adjusting the alignment easy, sway bar drops adjust the sway bar to its optimum position and a heavy 1/4″ thick differential skid plate protects the underside when off driving off road.

In the rear, full 4″ cast iron lift blocks with integrated bump stop wings provide enough lift to level the truck nicely. Rear Hydro or optional Nitro shocks finish out the installation and provide enough clearance for a maximum sized tire of 35×12.50.

Featured Technology & Benefits

  • Front and rear heavy duty 1-piece lower control arm crossmembers
  • Massive ductile cast iron steering knuckles
  • Full differential relocation bracket system included to properly correct CV shaft angles
  • Includes bolt-on strut spacers – strut disassembly not required
  • New eccentric cam bolts included for easy alignment
  • Includes sway bar relocation brackets to acheive optimum position for sway bar
  • 1/4″ thick differential skid plate included
  • 4″ Rear Blocks with integrated bump stop wings to acheive a more level stance
  • Rear Hydro shocks included – Nitro shocks upgrade is available.
  • Max recommended tire size: 35×12.50 (see tire/wheel fitment below)

Important Notes!

  • *Kit images show upgraded Nitro (black) shocks*
  • Requires frame bracket modification
  • 18″ wheels should be test fit to ensure proper tie rod end clearance. Wheel profiles can vary between manufacturers
  • Stock 17″/18″ wheels cannot be reinstalled. Stock 20″ wheels can be used with up to a 305/60R20 tire
  • Vehicles equipped with a 2-piece rear driveshaft may require carrier bearing drop kit D5405
  • Depending on wheel selection, minor trimming may be required to fit tire

This product fits the following applications:

  • 2015-2020 Ford F150 4WD

Quick Specs

  • Front Lift Height: 4″
  • Front Lift Method: Strut Spacer
  • Rear Lift Height: 4″
  • Rear Lift Method: Blocks
  • Install Time Hrs: 8-10
  • Difficulty Level 1-5: 4
  • Wheel Size: 18 x 9
  • Back Spacing: 5 – 5.5″
  • Max Tire Size: 35×12.50
  • Wheel Size: 20 x 9
  • Back Spacing: 5 – 5.5″
  • Max Tire Size: 35×12.50

F2634 Installation Manual



3404

on

Zone Offroad 4″ Leaf Spring Mini-Packs Lift Kit 2000, 2001, 2002, 2003, 2004, 2005 Ford Excursion 4WD

Part: F11

It’s time to upgrade your Excursion! The revolutionary new Zone 4″ lift kit system features new front leaf spring mini packs that are designed to not only ride great, but will hold up over the long haul. An adjustable track bar is included to properly center the axle after lifting. This track bar features new oversized urethane bushings for long term performance. Optional ZONE shocks (choose from drop down) were custom valved to work perfectly with the new Zone leaf springs to increase off road performance while still offering unmatched on road ride quality. With the front replacement track bar and the rear block kit, this system is one of the easiest installations on the market for a 4″ system.

Featured Technology & Benefits

  • New front leaf spring mini packs make for easy installation with an amazing ride
  • Adjustable track bar to properly center the axle
  • New front & Rear U-bolt with high nuts & washers
  • Rear 3″ Block kit for easy installation
  • Performance custom valved Zone Shocks optional (choose from drop down)

Important Notes!

  • Models with rear CV driveshaft may experience drive line vibration
  • Front and Rear driveshaft modification may be required
  • Due to OE variances, you may need to change the rear block to level the truck.

This product fits the following applications:

  • 2000 Ford Excursion 4WD
  • 2001 Ford Excursion 4WD
  • 2002 Ford Excursion 4WD
  • 2003 Ford Excursion 4WD
  • 2004 Ford Excursion 4WD
  • 2005 Ford Excursion 4WD

Quick Specs

  • Front Lift Height: 4″
  • Front Lift Method: Leaf Spring Mini-Packs
  • Rear Lift Height: 3″
  • Rear Lift Method: Block
  • Install Time Hrs: 7
  • Difficulty Level 1-5: 2
  • Wheel Size: 16 X 10
  • Back Spacing: 4″
  • Max Tire Size: 33 X 12.50
2393

on

Zone Offroad 4″ Strut Spacers Lift Kit 2016, 2017, 2018, 2019, 2020,2021,2022,2023 Toyota Tacoma 4WD

Part: T8

Zone Offroad’s 2016 Toyota Tacoma 4wd 4″ Suspension System gives current model owners a complete and affordable system to clear up to 33″ tires, including everything needed to properly outfit your new truck for safe, reliable performance where ever your journey may lead you.

Up front the kits include a pair of heavy duty 1/4″ thick crossmembers, full width differential skid plate, and multipoint differential relocation brackets to create a strong subframe. These combined with the ductile iron steering knuckles all the system to work with the factory ESC System parameters to keep you safe on the road. Finishing off the front of this kit are a pair of top mounted strut spacers, new bump stops, sway bar relocation brackets and all the hardware needed to install. In the rear of these kits is a block kit to level the stance, new u-bolts, brake line extension and your choice of Zone hydro or nitro gas shocks.

Choose your Tacoma suspension lift from Zone Offroad simply because it provides the best parts for the least amount of your hard earned cash with excellent customer service to back it up.

Featured Technology & Benefits

  • Heavy Duty 1/4″ Boxed Front & Rear Crossmembers
  • Full Width Belly Pan For Differential Protection And A Strong Sub-Frame
  • Solid Extended Ductile Iron Steering Knuckles
  • Stout Strut Spacers To Maintain Factory Struts And OE Ride Quality/Handling
  • Durable Black Powder Coat Finish
  • Over 90% Made In The USA

Important Notes!

  • Will not work on TRD Pro Models
  • Minor welding required (steering stops)
  • Requires frame bracket modification
  • Stock wheels cannot be reinstalled. 18″ or larger wheels must be used.
  • System will work on 2wd PreRunner models
  • 33×12.50 tires require trimming

This product fits the following applications:

  • 2016-2023 Toyota Tacoma 4WD

Quick Specs

  • Front Lift Height: 4″
  • Front Lift Method: Strut Spacers
  • Rear Lift Height: 3″
  • Rear Lift Method: Block Kit
  • Install Time Hrs: 6-8
  • Difficulty Level 1-5: 4
  • Wheel Size: 18×9 min.
  • Back Spacing: 4.5″
  • Max Tire Size: 33×12.50 *notes
4900

on

Zone Offroad 4″ Coil Springs Lift Kit 1993, 1994, 1995, 1996, 1997, 1998 Jeep Grand Cherokee ZJ

Part: J16

Prepare yourself for the perfect combination of off road performance and on road handling. This 4″ ZJ system offers dramatic improvement in wheel travel and performance. The new massive lower control arms drastically inscrease the strength over stock, are formed to clear the mount for more wheel travel and correct front alignment. These arms feature rubber bushings to absorb the road and offer a degree of flexibility. This system comes with a transfer case drop as well as rear pinion cam locks that rotate the rear pinion for proper driveline angles. With 4″ of lift, you can clear up to a 32″ tire with room to twist as well as use your Jeep for a daily driver.

Featured Technology & Benefits

  • Four new Zone coils are included that are capable of being fully compressed and they will always come back to their original height.
  • Front extended sway bar links are included. These links come with urethane bushings to increase performance and reduce body roll.
  • A rear track bar relocation system is included to perfectly center the axle under your ZJ.
  • A minimal transfer case drop is supplied to correct the driveline angle while maintaining as much ground clearance as possible.
  • 3″ bump stop extensions are included to protect your vehicle while still greatly increasing wheel travel
  • Massive front and rear longer control arms featuring rubber bushings for ride comfort and flexibility
  • New rear pinion cams are included to rotate the rear pinion for proper drive line angles.
  • The system is completed with optional 4 new Zone shocks that are specifically valved for your ZJ to perform well both on and off road.

Important Notes!

  • Measure front driveshaft prior to installation -over 24-1/2″ – no modification should be necessary, 20″ to 24″ you may need to change to spicer type joint if vibration occurs. If driveshaft is less than 20″ then a spicer type joint is required and vibration may persist.
  • Vehicles equipped with V8 may not achieve stated lift height. Front 3/4″ coil spacer is a common addition to this lift kit for the V8 models to accommodate the additional weight of the larger engine.
  • If equipped with CV style front driveshaft mount at the pinion, then a new spicer type u-joint is required to eliminate vibration.

This product fits the following applications:

  • 1993 Jeep Grand Cherokee ZJ 4WD Gas
  • 1994 Jeep Grand Cherokee ZJ 4WD Gas
  • 1995 Jeep Grand Cherokee ZJ 4WD Gas
  • 1996 Jeep Grand Cherokee ZJ 4WD Gas
  • 1997 Jeep Grand Cherokee ZJ 4WD Gas
  • 1998 Jeep Grand Cherokee ZJ 4WD Gas

Quick Specs

  • Front Lift Height: 4″
  • Front Lift Method: Coil Springs
  • Rear Lift Height: 4″
  • Rear Lift Method: Coil Springs
  • Install Time Hrs: 5-6
  • Difficulty Level 1-5: 3
  • Wheel Size: 15×8
  • Back Spacing: 3.5″ – 4″
  • Max Tire Size: 31 x 10.50
  • Wheel Size: 15×8
  • Back Spacing: 4.5″
  • Max Tire Size: 32 x 11.50
