Bilstein B8 5100 0-2.6″ Lift Coilovers with OE Replacement Coil Springs for 2015-2022 Chevy Colorado

Description
Bilstein B8 5100 0-2.6″ Lift Coilovers with OE Replacement Coil Springs for 2015-2022 Chevy Colorado

Bilstein B8 5100 0–2.6″ Lift Front Assembled Coilovers with OE Replacement Coil Springs for 2015–2022 Chevy Colorado

Part: BILOEC15

Need a complete front and rear setup?

Bilstein B8 5100 0–2.6″ Lift Coilovers with OE Replacement Coil Springs and Rear Bilstein Shocks for 2015–2022 Chevy Colorado

Adjustable Front Lift with Fully Assembled Bilstein 5100 Coilovers

These Bilstein B8 5100 front assembled coilovers are designed for 2015–2022 Chevy Colorado trucks equipped with a factory front coilover suspension.
They provide an adjustable front lift range of 0–2.6 inches using Bilstein’s snap-ring height adjustment system while retaining OE-style coil springs for proper ride quality and suspension geometry.

Each coilover arrives fully assembled with new top mounts, bushings, and hardware, making installation straightforward and eliminating the need for a spring compressor.

What’s Included

• (2) Front Bilstein B8 5100 shocks – Part No. 24-292702
• OE replacement front coil springs (option-dependent)
• New top mounts, bushings, and installation hardware
• Fully assembled front coilover units (left & right)

Front Coil Spring Options

• Standard OE replacement coils: For stock front-end weight and factory-style ride
• OE replacement coils for added front weight: Recommended for vehicles with steel bumpers, winches, or other front accessories

Select the correct coil option based on your vehicle’s front-end weight.

Front Shock Technical Details – Bilstein 24-292702

• Series: Bilstein B8 5100 (Ride Height Adjustable)
• Internal design: Monotube, gas pressure
• Body design: Snap-ring grooved coilover body
• Lift capability: 0–2.6″ front lift with OE replacement coils (application-specific)
• Collapsed length: 14.76″ (375 mm)
• Extended length: 19.45″ (494 mm)
• Stroke / travel: 4.69″
• Upper mount: Stem
• Lower mount: Eye (14.1 mm)
• Body diameter: 2.0″
• Piston diameter: 46 mm digressive piston
• Shaft diameter: 18 mm
• Finish: Zinc plated
• Reservoir: No
• Boot included: Yes (black bellows)
• Damping adjustment: No (fixed, application-tuned valving)

Why Choose Bilstein 5100 for Your Chevy Colorado

• Snap-ring height adjustment: Achieve lift without spacers or preload-based methods
• Monotube performance: Improved heat dissipation, fade resistance, and consistent damping
• Digressive piston valving: Firm control when needed with smooth everyday ride quality
• Improved handling: Reduced nose dive, better steering response, and increased front-end stability
• Ideal for daily driving and light off-road use

Fitment

• Vehicle: Chevy Colorado
• Model years: 2015, 2016, 2017, 2018, 2019, 2020, 2021, 2022
• Position: Front

Installation & Lead Time

• Coilovers are shipped fully assembled for easier installation
• Assembly lead time: Approximately 2–7 business days prior to shipment
• A professional alignment is required after installation

This Bilstein 5100 assembled coilover setup is a clean, adjustable solution for Colorado owners who want front lift with proper geometry, excellent ride quality, and long-term durability.
