Icon 0-3.5″ stage 8 Lift Kit W/ Tubular UCA For 2003-2009 Toyota 4Runner

Description
Icon 0-3.5″ stage 8 Lift Kit W/ Tubular UCA For 2003-2009 Toyota 4Runner

ICON 03-09 4Runner/FJ Cruiser 0-3.5 inches Lift Stage 8 Suspension System, Tubular UCA

Part Number: K53058T

Summary: The ICON Stage 8 suspension system is the ultimate performance upgrade for the 2003–2009 Toyota 4Runner and 2007–2009 FJ Cruiser, providing a versatile 0-3.5 inches lift range. This flagship system integrates 2.5 Series Extended Travel Coilovers with CDCV (Compression Damping Control Valve) and Omega Series Bypass rear shocks for unparalleled damping adjustability. Featuring a complete overhaul of the rear geometry with tubular upper and lower trailing arms plus an adjustable track bar, this system is engineered for maximum articulation and high-speed stability.

Features

• CDCV Technology: Compression Damping Control Valve provides 10 distinct settings to ensure precise ride tuning for varying terrain and vehicle loads.
• Omega Series Bypass: Position-sensitive internal bypass technology provides independent adjustment of rebound and compression to ensure optimal bottom-out control and ride comfort.
• Delta Joint Technology: The patented Delta Joint provides high-angle articulation with the durability of a sealed ball joint to ensure long-term reliability in harsh environments.
• Tubular Trailing Arms: CNC-bent 1026 DOM steel tubing provides increased strength and improved rear axle positioning to ensure superior off-road geometry.
• System Durability: CAD plating and hard-anodized finishes provide superior corrosion resistance to ensure component longevity in extreme conditions.
• Installation: A 100% bolt-on design provides a straightforward upgrade path to ensure minimal downtime and no permanent vehicle modifications.

Technical Specifications

Wheel & Tire Fitment

• OEM Wheels & Tires: Yes
• Aftermarket Wheels: 17×8.5 inches w/ 4.75” Backspace / 0mm Offset, 18×9 inches w/ 5.00” Backspace / 0mm Offset, or 20×9 inches w/ 5.00” Backspace / 0mm Offset
• Aftermarket Tires: 33 inches x 11.50 inches
• Note: Larger tires may fit but fender trimming and modifications will be required. Remote Reservoir Mounting Brackets May Interfere With Aftermarket Bumper Mounts / Windshield Washer Bottles. Coilover heights indicated are for a stock equipped vehicle.

System Components

• 58745C (qty: 1) | 07-09 FJ/03-09 4RNR/03-09 GX EXT TRAVEL CDCV COILOVER KIT
• 58451DJ (qty: 1) | 07-14 FJ/03-24 4RNR/03-23 GX TUBULAR UCA DJ KIT
• 54000T (qty: 1) | 07-14 FJ/03-24 4RNR/08-21 LC 200/03-23 GX TUBULAR LOWER TRAILING ARM KIT
• 54100T (qty: 1) | 07-14 FJ/03-24 4RNR/03-23 GX TUBULAR UPPER TRAILING ARM KIT
• 54200 (qty: 1) | 07-14 FJ/03-24 4RNR/03-23 GX REAR ADJ TRACK BAR KIT
• 52700 (qty: 1) | 07-14 FJ/03-24 4RNR/03-23 GX REAR 2 inches SPRING KIT
• 59910P (qty: 1) | 07-14 FJ/03-43 4RNR/03-23 GX 1-3\” REAR 2.5 VS RR OMEGA PAIR

Why Choose ICON Stage 8?

• Performance Engineering: Increased wheel travel and damping for superior control across all terrains.
• Delta Joint Reliability: High-angle articulation with a sealed design protects against road salts and trail debris.
• Fully Serviceable: Shocks are rebuildable and revalveable for long-term performance and custom tuning.

Frequently Asked Questions

Can I adjust the ride stiffness with this kit?
Yes
