ICON 0-3″ Lift Kit Stage 4 for 1996-2002 Toyota 4Runner

Description
ICON 0-3″ Lift Kit Stage 4 for 1996-2002 Toyota 4Runner

ICON 1996-2002 Toyota 4Runner 0-3 inches Lift Stage 4 Suspension System

Part Number: K53134

Summary: The ICON Stage 4 Suspension System for the 1996–2002 Toyota 4Runner is a comprehensive performance upgrade designed to maximize the capabilities of the 3rd Gen platform. This system provides a 0-3 inches front lift range and features 2.5 Series Remote Reservoir shocks for superior heat dissipation and damping consistency. The inclusion of Tubular Steel Upper Control Arms with ICON’s patented Delta Joint ensures increased wheel travel and corrected alignment geometry for the serious off-road enthusiast.

Features

• 2.5 Series Remote Reservoirs: 2.5-inch diameter shock bodies with external reservoirs provide increased oil volume for superior cooling to ensure consistent damping during aggressive off-road use.
• Delta Joint Technology: Patented high-angle ball joints provide the durability of a uniball with the weather resistance of a sealed joint to ensure long-term reliability and quiet operation.
• Tubular Upper Control Arms: CNC-bent tubular steel construction provides improved strength and corrected caster/camber to ensure proper alignment at lift heights up to 3 inches.
• System Durability: CAD-plated coilover bodies and 6061 aircraft-grade aluminum components provide maximum corrosion resistance to ensure performance in harsh environments.
• Installation: A 100% bolt-on design provides a straightforward installation process to ensure no major vehicle modifications are required.

Technical Specifications

Wheel & Tire Fitment

• OEM Wheels & Tires: Yes
• Aftermarket Wheels: 17×8.5 inches w/ 4.75” BS / 0mm Offset, 18×9 inches w/ 5.00” BS / 0mm Offset, or 20×9 inches w/ 5.00” BS / 0mm Offset
• Aftermarket Tires: 33 inches x 11.25 inches
• Note: Larger tires may fit but fender trimming and modifications will be required. Remote reservoir mounting brackets may interfere with aftermarket bumper mounts or windshield washer bottles.

System Components

• 58716 (qty: 1) | 96-02 4RUNNER 2.5 VS EXT TRAV RR COILOVER KIT
• 58400DJ (qty: 1) | 96-04 TACOMA/96-02 4RNR TUBULAR UCA DJ KIT
• 53015 (qty: 1) | 96-02 4RUNNER 1 inches REAR COIL SPRING KIT
• 57800P (qty: 1) | 96-02 4RUNNER REAR 2.5 VS RR PAIR

Why Choose ICON Stage 4?

• Performance Engineering: Increased wheel travel and vehicle-specific damping for superior control on and off-road.
• Delta Joint Reliability: Combines high-angle articulation with a fully sealed design for longevity in all climates.
• Fully Serviceable: All ICON shocks are rebuildable and revalveable, allowing for custom tuning and a lifetime of use.

Frequently Asked Questions

Are the shocks in this system adjustable?
Yes, the front coilovers are adjustable from 0-3 inches of lift height to accommodate different vehicle setups and weights.

What is the benefit of the Delta Joint?
The Delta Joint is a heavy-duty high-angle ball joint that allows for maximum suspension cycling without the accelerated wear associated with traditional uniballs.
