Bilstein 6112 .06-2.5″ Front Assembled Coilovers Kit for 2005-2015 Toyota Tacoma
Sale!
Description
Bilstein 6112 .06-2.5″ Front Assembled Coilovers Kit for 2005-2015 Toyota Tacoma
Bilstein 6112 .06-2.5″ Front Series Coilovers (Assembled) Kit for 2005, 2006, 2007, 2008, 2009, 2010, 2011, 2012, 2013, 2014, 2015 Toyota Tacoma
Part Number: 47-309975 , old: 46-241627 – ASSEMBLED with KYB top mounts, bushings, hardware
Designed for the serious off-road adventure seeker, the all new BILSTEIN 6112 Series Kit is the ultimate suspension solution. The 6112 Series optimizes off-road and on-road capabilities with a 60mm digressive piston for increased damping control. This kit features specially designed cold wound springs and an adjustable spring seat which allows for vehicle leveling, larger tires, and increased ground clearance. The kit comes with (2) 60mm shocks (2) springs and (2) billet spring seats. The 6112 is a direct bolt on application for late model half-ton trucks and SUVs which utilize a factory coilover suspension. The 6112 kit is for front applications and reuses the OEM top mount and spring isolators. To maximize performance, Bilstein recommends a 5160 Series remote reservoir shock for the rear
Installation Instruction:
https://productdesk.cart.bilsteinus.com//media/products/bilstein/E4-WM5-Y690A00.pdf
Questions and answers of the customers
-
Hello… Can you advise, based on customer feedback and/or actual experience, what may be the actual amount of front spring settling ?? Current rear stock wheel fender height is approximately 2.5” and front wheel fender height is approximately 2” (measured from mid wheel hub to bottom of fender). Need to decide which setting to order, 2.3 or 2.5… Thanks in advance..
-
0 votesQ Hello… Can you advise, based on customer feedback and/or actual experience, what may be the actua...... Read moreA It is better to choose 2.3”. Immediately after installation, new Bilstein springs usually provide about 0.25” more lift than advertised. After about 1,000 km, they will settle by ~0.3”, and the front will stabilize at around 2.25”–2.3”. If you go with the 2.5” setting, even after settling, the front of the truck will remain level with (or higher than) the rear, and even a minimal load in the bed will cause the front end to squat and look high.
Can you get different load coils or clip locations to make it accommodate a heavy bumper and winch?
-
0 votesQ Can you get different load coils or clip locations to make it accommodate a heavy bumper and winch?A we can recommend stronger springs for 6112 * * * https://www.suspensionlifts.com/shop/toyota-tacoma/2016-and-up/front-lifts-2/bilstein-b12-front-80-140lb-coils-for-6112-kit-for-2005-2019-toyota-tacoma/
If I were to buy these, could you set the clips to 1 and 2?
-
0 votesQ If I were to buy these, could you set the clips to 1 and 2?A We can, but we can’t guarantee results because manufacturer recommends different clip settings for 05-15 tacoma for these coilovers.A Just add the desired clip you want in the order notes.A yes we can but it will give stock height or even slightly less
If I use my stock rear shocks what height do I need to set the front springs on to get it level.
-
0 votesQ If I use my stock rear shocks what height do I need to set the front springs on to get it level.A In order to figure out how much lift you need to level please take existing measurements from center of the wheel hub to the bottom of the fender. Difference between front and rear is how much lift you need to level. https://www.suspensionlifts.com/level.png usually middle clip setting for leveling
